MAKBIA

Operational Conditions:

Temperature:-20oC to +120oC
Pressure:=1.0MPaSpeed:=15m/s

Materials:

Stationary Ring: Ceramic(Alumina),Silicon Carbide Reaction Bonded, Silicon Carbide Sintered Pressureless, Ni-binder Tungsten CarbideRotary Ring: Resin Impregnated Carbon Graphite(Furan),Antimony Impreg. Carbon Graphite, Silicon Carbide Sintered Pressureless, Silicon Carbide Reaction Bonded
Secondary Seal: Fluorocarbon Rubber(Viton), Nitrile(NBR),Ethylene Propylene(EPDM), Spring and Metal Parts: Stainless Steel,Stainless Steel

Applications:

Clean Water,Sewage Water,Oil and other moderately corrosive fluids.
