MAK102

Operational Conditions:

Temperature:-20oC to +120oC
Pressure:=1.4MPa
Speed:=15m/s

Materials:

Stationary Ring: Ceramic(Alumina),Silicon Carbide Reaction Bonded, Silicon Carbide Sintered Pressureless, Ni-binder Tungsten Carbide, Co-binder Tungsten Carbide Rotary Ring: Resin Impregnated Carbon Graphite(Furan),Antimony Impreg. Carbon Graphite, Silicon Carbide Sintered Pressureless, Silicon Carbide Reaction Bonded, Co-binder Tungsten Carbide, Ni-binder Tungsten Carbide Secondary Seal: Nitrile(NBR),Ethylene Propylene(EPDM),Fluorocarbon Rubber(Viton) Spring and Metal Parts: Stainless Steel, Stainless Steel

Applications:

Clean Water, Sewage Water, Oil and other moderately corrosive fluids

•
•
